| Place of Origin: | China |
| Brand Name: | AEO |
| Certification: | CE, FCC |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | negotiation |
| Packaging Details: | package and carton |
| Delivery Time: | 3-4 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10000 pcs/month |
| Backplane Capacity: | 64G | Cache: | 4.1M |
|---|---|---|---|
| MAC Address Table: | 16K | Maximum Frame Size: | 10000bytes |
| IPC/VLAN Dip Switch: | Yes | Max Voltage Range: | AC 90～264V；47/63Hz |
| Working Temperature: | -10~60°C | Relative Humidity: | 5% ~ 90% |
| Power Consumption: | 36W | Level Of Protection: | IP30 |
| Standard Protocol: | IEEE802.3af/at | Pin Definition: | V+ V+ V- V-Corresponding To 4，5，7，8 |
| Output Power: | IEEE802.3af：15.5W IEEE802.3at：25.5W | Output Power: | 250W |
| Protection Grade: | IP30 | Layer2 Loop Protocol: | STP/RSTP/MSTP Protocol |
| MTBF: | 100000 Hours | ||
| High Light: | Managed POE Ethernet Switch,10000 bytes POE Ethernet Switch,56G power over ethernet switch 24 port |
||
Managed 24 Port POE Network Switch 24 Gigabit POE and 4 Gigabit SFP and 4 Gigabit Ethernet Ports
Technical Parameter
| Ethernet POE port | 24 | |
| Combo port | 4 | |
| Management port | One Console port | |
| Ethernet & SFP Port | 10/100/1000Mbps | |
| Exchange capacity | 56G | |
| Layer2 forwarding rate | 36Mpps | |
| Max Frame length | 10000bytes | |
| Cache | 4.1Mbit | |
| Switch mode | Store and Forward | |
| Port |
IEEE 802.3x flow control(full duplex) Supports PPS - based broadcast storm suppression |
|
| Trunk |
LACP Manual polymerization Supports MAX 8 aggregation groups, each of which supports MAX eight ports |
|
| MAC Address |
• Max 16K MAC • Support the black hole MAC |
|
| VLAN |
• Support for port-based VLANs (4K) • GVRP • VLAN VPN (QinQ) |
|
| Multicast |
• IGMP Snooping • IGMP V1/V2/v3 |
|
| Layer2 loop protocol | • STP/RSTP/MSTP protocol | |
| Mirror |
• N:1 port mirror • Support stream mirroring |
|
| ACL |
• Support L2-L4 packet filtering function, provide based on source MAC address, destination MAC address, source IP address, destination IP address, port, protocol type, etc • Timetime-based ACL are supported |
|
| QoS |
• Supports restrictions on the rate at which messages can be received and sent on the port • Support 802.1p and DSCP priority relabeling of packets • Support message redirection • Supports 8 port output queues • Support for flexible queue scheduling algorithms (SP, WRR, SP+WRR) |
|
| Security features |
• Support IEEE 802.1X authentication/centralized MAC address authentication • AAA&RADIUS authentication support • Supports MAC address learning limit • Support MAC address binding with port and IP • support SSH2.0 • Supports ARP intrusion detection • Support port isolation • Supports MAC address black holes |
|
| Management and maintenance |
• Support for WEB/TFTP loading upgrades • Support command line interface (CLI), Telnet, Console port for configuration • Support SNMPV1/V2/V3, WEB network management • Support system logging, hierarchical alarm, debugging information output • Support for PING and Tracert • Support for DLDP (Device Connection Detection Protocol) • Support port loopback detection |
|
| Input Voltage |
•Rated voltage range:AC 100～240V ；50/60Hz • Max voltage range:AC 90～264V；47/63Hz |
|
| Max power consumption | 36W | |
| Working temperature | -20℃ to 70℃ | |
| POE | Standard protocol | IEEE802.3af/at |
| Pin definition | V+ V+ V- V- to 1,2,3,6 | |
| Total output power | 250W | |
| Working humidity | 5% to 95% RH (No condensation) | |
| MTBF | 100000 hours | |
| Enclosure material | Metal case | |
| Protection grade | IP30 | |
Product Introduction
The Managed 24 Port POE Network Switch is a full-gigabit layer2 network management POE switch independently developed and designed for the construction of high-performance gigabit network requirements. It has 24 RJ45 ports of POE gigabit and 4 gigabit Combo ports. It is easy to manage and maintain, and can meet the networking and access requirements of enterprises, intelligent communities, hotels, office networks and campus networks.
Product Features
● Support IEEE 802.1Q VLAN, Voice VLAN and other rich VLAN functions to meet the needs of different users and make networking more convenient, efficient and secure.
● Support port IEEE802.1P and DSCP priority mode, support Equ, SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR four queue scheduling algorithms, ensure the priority of key business data processing; Support flow control function, can allocate bandwidth reasonably; Support voice VLAN to ensure the quality of calls.
● Strong hardware ACL capability, support L2~L4 data flow classification; Support ACL based on port, VLAN, easy to achieve network monitoring, traffic monitoring, priority re-marking and data forwarding control; Support ACL control based on time, convenient to achieve access requirements for accurate control of time; Support port based and MAC based 802.1X authentication, easy to set user access rights.
● Support Port/MAC/IP/VLAN ID intelligent scanning binding, quickly locate user information, easy operation, simplify network management; Combined with ARP attack protection function to completely solve the ARP spoofing and attack; Support port security, can limit the number of port MAC address learning, effective defense against MAC address attack; Support DoS attack protection, effectively ensure network security.
● Support STP/RSTP/MSTP layer2 link protection technology, greatly improve the fault-tolerant, redundant backup capacity of the link, to ensure the stable operation of the network; Provide manual convergence, static LACP, dynamic LACP convergence mode, effectively increase link bandwidth, improve link reliability, and at the same time to achieve load balance, link backup; Multicast management is supported. IGMP Snooping technology can be used to effectively control network congestion caused by multicast flooding.
● Support CLI command line (Console, Telnet, SSHV1/V2), Web network management (HTTP, SSL V2/V3/TLSV1), SNMP (V1/V2c/V3) and other management methods, fast and convenient network management; Support user classification, identity filtering and other functions to enhance configuration security; Support port data monitoring, monitoring network status, easy to achieve unified global network management, convenient and flexible.
Product picture
● All of our package are international standard package
● We will deliver our products as soon as the order confirmed
