| Place of Origin: | China |
| Brand Name: | AEO |
| Certification: | CE, FCC |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | negotiation |
| Packaging Details: | package and carton |
| Delivery Time: | 3-4 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10000 pcs/month |
| MAC Address Table: | 8K, Auto-learning, Auto-aging | Transfer Mode: | Store-and-Forward |
|---|---|---|---|
| Maximum Packet Length: | 9KB | Switching Capacity: | 56G |
| Power Input: | AC: 100~240V, 50/60Hz | Power Output: | DC: 55V/ 4.5A, 55V /5.6A (Optional) |
| High Light: | CE Giga Poe Switch,8K Giga Poe Switch,240V Managed Fiber Switch |
||
24+4 Giga Poe Switch Web Managed Fiber Switch Support 802.3af/at
Technical Parameter
| Standard | IEEE802.3, IEEE802.3u, IEEE802.3ab,IEEE802.3z, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at |
| Network Media(Cable) | 10BASE-T: UTP category 3,4,5 cable (≤100m) 100BASE-TX: UTP category 5,5e cable (≤100m) 1000BASE-T: UTP category 5e,6 cable(≤100m) |
| SFP Slots | 4-Port 1000BASE-LX/SX SFP interface(Port25 and port 26) |
| LED | System: Power (Green) Per port: PoE (Orange) LINK/ACT: 10/100M (Orange) 1000M(Green) |
| MAC Address Table | 8K, Auto-learning, Auto-aging |
| Transfer mode | Store-and-Forward |
| Maximum packet length | 9KB |
| Switching Capacity | 56G |
| Dimensions (LxWxH) | 440 x 232 x 45 mm |
| Weight | |
| Fan | Fan |
| Power Input | AC: 100~240V, 50/60Hz |
| Power Output | DC: 55V/ 4.5A, 55V /5.6A (Optional) |
| PoE(Power Over Ethernet) | |
| PoE port | Port1~24 |
| PoE Power on RJ-45 | Even port: Mode A 1/2(+),3/6(-) (Port:2,4,6,8,10,12,14,16,18,20,22,24) Odd port: Mode B 4/5(+), 7/8(-) (Port:1,3,5,7,9,11,13,15,17,19,21,23) |
| PoE Power Output | Per port 55V DC Max.32W |
| PoE Power Budget | 240W/300W (Optional) |
| Environmental | |
| Operating Temperature | 0°C ~ 40 °C (32 °F ~104°F ) |
| Storage Temperature | -40 °C ~ 70 °C (-40 °F ~158°F ) |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Humidity | 5% ~ 90% non-condensing |
Product Introduction
24-port 10/100/1000Mbps PoE switch with 4 SFP Slots. The PoE ports can automatically detect and supply power to IEEE802.3af/at compliant Powered Devices (PD). The electrical power and data transmission on the same cable can expand your network to the places where no power lines or outlets, where you can install devices such as APs, IP cameras, or IP phones etc.
Product Features
Interface information
24 10/100/1000Mbps RJ45 Ports support poe function
4 1000Mbps SFP Slots
PoE(Power over Ethernet)
Complies with IEEE802.3af/at Power over Ethernet
Supports PoE Power up to 32W for each PoE port
Support the two power supply modes for PoE (Mode A and Mode B)
Auto detect power device
Remote power and Data feeding up to 100m
Switch
IEEE 802.3X pause frame for full-duplex,back pressure for half-duplex.
Flow Control for Full Duplex operation and back pressure for Half Duplex Operation
8K MAC address, automatic address learning and address aging
Support Energy-Efficient Ethernet (EEE) function (IEEE802.3az)
Built-in power supply can be chosen by the customer
Support web smart management interface
Support port mirror, gathering, bandwidth control, storm suppression, QoS, VLAN,STP,ETC
Product picture
● All of our package are international standard package
● We will deliver our products as soon as the order confirmed
