| Place of Origin: | China |
| Brand Name: | AEO |
| Certification: | CE, FCC |
| Minimum Order Quantity: | 1 pair |
|---|---|
| Price: | negotiation |
| Packaging Details: | package and carton |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T |
| Supply Ability: | 10000 pairs/month |
| Optical Wavelength: | 1310/1550nm | Output Power: | -8~3dBm |
|---|---|---|---|
| Receiving Sensitivity: | -30dBm | Interface: | FC/ST/SC/LC |
| Bandwidth: | 8MHZ | Compatible Systems: | NTSC/PAL/SECAM |
| Impedance/Voltage: | BNC 75Ω (unbalanced) / 2.0Vp-p | ||
| High Light: | SECAM Compatible Video Fiber Converter,Custom NTSC Compatible Video Fiber Converter,SECAM Compatible Fiber Video Converter |
||
Video Fiber Converter Customized Video, Data, Ethernet, Telephone, Audio, Contact Closure
Technical Parameters
| Optical | |
| Wavelength | 1310nm/1550nm |
| Output Power | -8~3dBm |
| Optic Fiber |
Single mode (9/125um) 20Km to 80Km Multimode (50/125um) 1Km, ( 62.5/125um) 500m |
| Receiving Sensitivity | -30dBm |
| Interface | FC/ST/SC/LC |
| Video | |
| Bandwidth | 8MHZ |
| Compatible Systems | NTSC/PAL/SECAM |
| Impedance/Voltage | BNC 75Ω (unbalanced) / 2.0Vp-p |
| Differential Gain | < ±1% |
| Differential Phase | < ±1 |
| S/N ratio | >60dB(weighting)(8 bit) |
| Interface | BNC |
| Data | |
| Data Protocol | RS232, RS422, RS485, Manchester, BIPHASE data |
| Bandwidth | 0~300kbps |
| Error rate | 10-9 |
| Interface | Phoenix terminal |
| Audio | |
| Impedance / Voltage | 600ohm(unbalanced) / 2.0Vp-p |
| Frequency Response | 10~20kHz |
| Total Harmonic Distortion | <0.05% |
| Differential Phase | < ±1 |
| S/N ratio | >95dB(weighting) |
| Interface | Phoenix terminal |
| Contact Closure | |
| Signal Input | Alarm, Binary input, support TTL, RS-232/422/485 or passive switch button |
| Signal Output | Arbitrary alarm, Binary output, support TTL, RS-232/422/485 or relay output |
| Interface | Phoenix terminal |
| Telephone | |
| Phonetic Bandwidth | 8KHz |
| Work Mode | Point to point hot line, program controlling switch/extension mode |
| Distortion | <1% |
| S/N Ratio | >95dB |
| Interface | RJ11 or RJ45 |
| Ethernet | |
| Work Mode | Full duplex / half duplex, autosensing |
| Network Speed | 10/100Mbps, autosensing |
| Interface | RJ45 |
| Chassis and Cards | |
| Chassis Slots Quantity | 18 slots |
| Compatibility(with cards) | 1~4ch cards(18pcs); 8ch cards(9pcs) |
| Flexibility | Supports mixed installation of different configurations |
| Cards |
In 4ch PCB(153x100x10mm) or 8ch PCB size (153x100x25mm) configurations which require larger size can’t be used with this system |
| Electrical.Environmental.Mechanical | |
| Operating Voltage | Standalone:220VAC to 5V/12VDC, Rack: dual 220V/-48V AC, card: powered by chassis |
| Operating Temperature | -35℃～+75℃ |
| Storage Temperature | -45℃～+85℃ |
| Humidity | 0~95% non-condensing |
| Dimension And Weight | Standalone and card: depends on different configurations, Chassis: 19”3U |
Product introduction
Optical video transmitter and receiver are designed to extend the coaxial limit of 500 meters and get CCTV signals connected to 80km max on optical fiber cable. Also referred to as fiber converters, media converters, optical video converters, Optical video transmitter and receiver are a pair of CCTV transmission devices that transmit and receive high fidelity CCTV signals of video, audio, data, telephone, contact closure, Ethernet, etc. with advanced optical transmission technology which enables lossless transmission with minimum disturbance. And the plug-and-play design enables simple installation.
Product features
1. Robust metal casing
2. Lightning-proof solution
3. Low optical link loss – max 30dB
4. Without EMI, RFI and ground loop
5. Bi-di transmission on 1 fiber with WDM
6. Hot plug-and-play with switch power supply
7. Available in standalone and 3U rack systems
Product picture
● All of our package are international standard package
● We will deliver our products as soon as the order confirmed
