AC220V AC24V DC12V Intelligent IOT Box Remote Control Web Managed Platform

AC220V AC24V DC12V Intelligent IOT Box Remote Control Web Managed Platform

  • AC220V AC24V DC12V Intelligent IOT Box Remote Control Web Managed Platform
AC220V AC24V DC12V Intelligent IOT Box Remote Control Web Managed Platform
Product Details:
Place of Origin: China
Certification: CE, FCC
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: package and carton
Delivery Time: 3-4 working days
Payment Terms: T/T, L/C
Supply Ability: 10000 pcs/month
Contact Now
Detailed Product Description
Intelligent Bluetooth Lock: Support GPS: Support
Pinhole Camera: Support Operating Temperature: -40°C~+85°C
UK 3-hole Socket: Support AC220V Power Output: 5 Sets
High Light:

anti-surge Intelligent Monitoring Box

,

DC12V Intelligent Monitoring Box

Ac220v Ac24v Dc12v Intelligent IOT Box Remote Control Web Managed Platform




Technical Parameter

Operation
and
Maintenance
Data control
Main control board parameters
Flash:4GByte
DDR: 512MByte
CPU: ARM 600MHz
Unauthorized unpacking monitoring alarm and video
Illegal unpacking alarm, video recording, and upload.
Power failure alarm
DC12V power failure alarm
AC220V mains power failure alarm
Fan status monitoring alarm
Fan failure alarm
Fan speed control
Temperature detection alarm
Alarm temperature setting,
Above the upper-temp limit, start the fan to dissipate heat;
Less than the lower temp limit, start the chassis heating (The heating module needs to be purchased separately)
Water leak detection alarm
Chassis flooding alarm
Power monitoring alarm
Real-time alarm for mains over-voltage, under-voltage, lightning strike,short circuit fault
Lightning protection frequency monitoring
Count lightning strike times to protect equipment installation and maintenance in advance
Power consumption statistics
Real-time display of chassis voltage, current, power
Output voltage / current control and monitoring alarm
DC12V output control and alarm
AC24V output control and alarm
AC220V output control and alarm
PoE power output control and alarm
SMS alarm
The platform sends an alarm message SMS to the mobile phone of the operation and maintenance personnel
Network transmission
PoE output network management
Delay start of power supply
Scheduling of PoE operation and time
PoE port real-time power viewing,
PoE port power priority configuration
PoE output power allocation, off& af &at
PoE switch network management configuration
DHCP Serve, IGMP multicast
Port mirroring, Port rate setting
Network VLAN division
Link aggregation, QoS configuration
Network storm suppression
MAC + VLAN + IP + port binding
IPV4 / IPV6 dual stack protocol
802.1X access control, 802.3X flow control
ERPS and spanning tree ring network networking, etc.



Product Overview

Intelligent Monitoring Box is an intelligent power control system with high integration, strong functionality, and simple use and installation. It adopts a frame structure, providing AC220V, AC24V, DC12V multiple sets of voltage output, detection, and remote control.



Features

◇ The built-in 40KA power supply anti-surge and lightning protection module can effectively reduce the damage to the internal equipment caused by the surge current and ensure the stable operation of the equipment.

◇ Provide a power box door alarm switch to detect the status of the box door, prevent the abnormal opening of the equipment box, and support the management platform to monitor the box door status in the real-time, arm, disarm, and other modes.

◇ Built-in automatic reclosing, when a leakage,over-voltage, under-voltage, over-current, short circuit, and other power failures occur, it can automatically disconnect and close. When the fault is eliminated, it can return to normal working status. At the same time, the relevant power data and the number of lightning strikes are displayed to the management platform in real-time.

◇ Support network equipment expansion (network switch, ONU equipment, etc.), real-time monitoring of network connection status, and remote restart of network equipment improving network connection reliability.

◇ Support power box dynamic ring monitoring and real-time linkage with the management platform, including but not limited to unpacking alarm, power failure alarm, network failure alarm, water leakage alarm, temperature and humidity alarm, unpacking lighting, etc.

◇ Support multiple types, multiple sets of output voltage, voltage data acquisition, and remote control, support 1*AC220V maintenance power supply, no less than 5*AC220V power output, 2*AC24V power output, and 3*DC12V power output. Each power supply can be individually remotely controlled on/off and power-down alarm.


Product picture

AC220V AC24V DC12V Intelligent IOT Box Remote Control Web Managed Platform 0

Packaging & Shipping



● All of our package are international standard package
● We will deliver our products as soon as the order confirmed

AC220V AC24V DC12V Intelligent IOT Box Remote Control Web Managed Platform 1
